ABB 3BHE036342R0101 XD D501 A101 | High Voltage Inverter Board – Latest Model

Input Voltage Range:3000V DC

Output Power:Up to 1000kW

Frequency Control:AC variable frequency up to 400Hz

Protection Class:IP67

Temperature Rating:-40°C to +60°C

Load Management Capacity:Dynamic load balancing

Cooling Method:Air cooling with built-in fans

Communication Interface:Modbus RTU, Ethernet IP

    Introducing the latest model of our high voltage inverter board, the ABB 3BHE036342R0101 XD D501 A101. This cutting-edge component is designed for advanced industrial control systems, ensuring unparalleled performance in high-voltage environments.

    Engineered with precision and efficiency, this inverter board delivers exceptional power conversion capabilities, making it ideal for complex applications where reliability and safety are paramount.

    Featuring an expansive input voltage range from 3000V to 6900V, our product is versatile enough to meet diverse operational needs across various industries. Its output current capacity of up to 101A further enhances its suitability for high-demand scenarios.

    Operated within a temperature range of -25°C to +55°C, this inverter board is built to withstand harsh conditions, ensuring consistent performance even in extreme environments. It complies with stringent international standards including CE, UL, and IEC, guaranteeing reliability and safety.

    In terms of dimensions, the ABB 3BHE036342R0101 XD D501 A101 measures 200mm in width, 300mm in height, and 150mm in depth, making it compact yet powerful. With a weight of just 10kg, it offers easy integration and installation in your existing systems.
