ABB PM820-1

The ABB PM820-1 is a power meter module from ABB’s M4M System series, designed for energy monitoring and power management in industrial and commercial applications. Below are its key technical parameters:

General Specifications:

• Model: PM820-1 (part of the M4M System)
• Type: DIN-rail mounted power meter
• Standard Compliance: IEC 61557-12, IEC 62053-21/22, EN 50470-1/3

Electrical Parameters:

• Nominal Voltage (Un):
  • 3-phase: 3 × 230/400 V AC (phase-to-phase)
  • Single-phase: 230 V AC
• Measurement Voltage Range:
  • 0.7 to 1.2 × Un (continuous operation)
• Current Input:
  • Direct Connection: Up to 6 A (via internal shunt)
  • External CT (Current Transformer): Typically 1 A or 5 A (configurable)
• Frequency Range: 45–65 Hz

Measurement Capabilities:

• Voltage (V): L-N, L-L (per phase & average)
• Current (A): Per phase & neutral
• Active Power (kW, MW): Per phase & total
• Reactive Power (kVAR, MVAR): Per phase & total
• Apparent Power (kVA, MVA): Per phase & total
• Power Factor (PF): Per phase & total
• Frequency (Hz): System frequency
• Energy Measurement:
  • Active Energy (kWh, MWh) (import/export)
  • Reactive Energy (kVARh, MVARh) (quadrant-based)

Accuracy Class:

• Voltage & Current: ±0.5% of reading
• Active/Reactive Power: ±1.0%
• Energy Measurement: Class 1 (IEC 62053-21/22)

Communication & Interfaces:

• Communication Protocols:
  • Modbus RTU (RS-485)
  • M-Bus (optional)
• Pulse Outputs:
  • 2 × S0 Pulse Outputs (for energy pulses, configurable)

Environmental & Mechanical:

• Operating Temperature: -25°C to +55°C
• Storage Temperature: -40°C to +70°C
• Humidity: 5–95% RH (non-condensing)
• Protection Class: IP20 (for indoor use)
• Mounting: DIN-rail (35 mm)

Power Supply:

• Auxiliary Supply (Vs):
  • 24–60 V DC or 100–240 V AC/DC (depending on variant)

Applications:

• Energy monitoring in switchboards, distribution panels, industrial plants
• Power quality analysis
• Integration with ABB M4M, ABB Ability™, or third-party SCADA systems
