ABB S-093N 3BHB009885R0021

ABB S-093N Overview

Product Type:
High-voltage inverter phase module adopting IGCT (Integrated Gate-Commutated Thyristor) technology.

Order Code: 3BHB009885R0021
Manufacturer: ABB (Switzerland) — a core component of the ACS-series medium-voltage drives.

---

Key Technical Specifications

Parameter	Value / Description
Rated Voltage	3.3 kV (max. DC 4.5 kV)
Power Range	4 – 40 MVA (per module), scalable up to 120 MVA in parallel
Topology	Three-level NPC (Neutral Point Clamped), bidirectional four-quadrant operation
Switching Device	4500 V reverse-conducting IGCT
Efficiency	> 98 % (at full load, 50 Hz)
Cooling Method	Forced air cooling (standard) / Deionized water cooling (optional)
Control Interface	Optical fiber ST port, compatible with AC 800 PEC
Communication Protocols	Profibus DP, Modbus TCP, EtherCAT
Dimensions (L × W × H)	320 × 190 × 130 mm
Weight	≈ 9.5 kg
Protection Functions	Overload, short circuit, overvoltage, low-voltage ride-through, anti-islanding
Certifications	CE, UL, IEC 61800-4, RoHS

---

Key Technical Highlights

• Press-pack IGCT without bonding wires:
  Withstands short-circuit currents up to 10 × rated (10 ms); fatigue lifetime is approximately 3 times longer than conventional IGBT modules.
• Three-level NPC + soft busbar design:
  Stray inductance < 5 nH; turn-off overvoltage reduced by 15 %; dv/dt optimized to 3 kV/µs, reducing motor winding stress.
• Four-quadrant energy recovery:
  During braking or load reduction, energy is automatically fed back to the grid—no braking resistor required—saving 3–5 % energy annually.
• Dual-mode cooling:
  Air-cooling thermal resistance 0.08 K/W; water-cooling can reduce cabinet height from 2.2 m to 1.8 m, saving ≈ 20 % installation space.

---

Typical Application Scenarios

Industry	Application Example	Value Added
Wind Power	14 MW offshore unit (Inner Mongolia) using 3 parallel S-093N modules achieved 75 % voltage dip ride-through for 625 ms, meeting latest State Grid connection standards.	Improved grid connection reliability; reduced downtime risk.
Metallurgy	Hebei 2250 mm hot-strip mill (F4 finishing stand) upgraded with 6 S-093N modules (10 MW total). Rolling speed increased by 12 %; power consumption per ton of steel reduced by 6 %; annual energy savings ≈ 12 million kWh.	Higher productivity, significant energy savings.
STATCOM / Reactive Compensation	14 MW offshore wind-farm STATCOM system using S-093N four-quadrant modules kept voltage fluctuations within ±2 %.	Ensures high-voltage ride-through and improves grid power quality.

---

Selection & Procurement Recommendations

• Voltage and Power Matching:
  Choose single or parallel modules based on system rated voltage (3.3 kV or 4.16 kV) and required output power.
• Cooling Mode:
  For space-constrained or high-dissipation environments, prefer deionized water cooling; for standard cabinets, forced air cooling is sufficient.
• Control Compatibility:
  Ensure use of ABB AC 800 PEC controllers or compatible fiber-optic interfaces to enable complete protection and monitoring functions.
