Allen-Bradley 1746-A7 SLC500 I/O Chassis

Model Type:SLC500

Model Number:1746-A7

Manufacturer:Allen Bradley

I/O Chassis Type:SLC Series

Capacity:7 Slot

Mounting:Panel

Temperature Rating:0 – 60 DEG C

Enclosure:Open Type

Form Factor:Slot Type Chassis

Cooling:Convection

Dimensions:{“Length”:”5.8 IN”,”Width”:”11.3 IN”,”Height”:”6.8 IN”}

Maximum Backplane Current:5.1 VDC At 10 A, 24 VDC A 2.88 A

Weight:2.4 LB Without Modules

Power Consumption:1.8 W

Power Dissipation:6.1 BTU/HR

Standards:KC certified, GOST, MARINE SPECIFICATIONS

    The Allen-Bradley 1746-A7 SLC Series I/O Chassis is engineered to deliver superior performance and reliability in demanding industrial settings. With its open-type enclosure and convection cooling, this chassis ensures efficient operation even under challenging conditions. Designed to mount easily on panels, it supports up to 7 slot configurations, making it ideal for various automation applications. Its robust design includes a temperature rating of 0 – 60 DEG C, ensuring consistent performance across a wide range of temperatures. The compact dimensions of 5.8 IN x 11.3 IN x 6.8 IN make it easy to integrate into existing systems without sacrificing space. With a maximum backplane current of 5.1 VDC at 10 A and 24 VDC at 2.88 A, this chassis provides ample power for multiple modules. The lightweight design (2.4 LB without modules) adds to its ease of installation and handling. Additionally, it complies with stringent certifications such as KC, GOST, and Marine specifications, ensuring safety and reliability in critical applications.
