Allen Bradley 1746-OV16: 16-Channel DC Output Module – Precise Control for Industrial Automation

Module Type:Discrete Output

Nominal Input Voltage:24VDC

Input Voltage Range:10-50 VDC

Backplane Current Consumption:0.270 A

Voltage Range:10-50 Volts DC

Sink Outputs:16

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load:1 MA

Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A at 60°C, Continuous Current Per Module: 4 A at 60°C

Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC

Processor:SLC 500

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% humidity

    Integrating advanced technology, the Allen-Bradley 1746-OV16 is engineered to deliver exceptional performance in industrial control applications. Its compact design and efficient power handling capabilities make it a preferred choice for complex automation scenarios.

    With its 16-channel configuration, this module ensures precise control over various processes, enhancing operational efficiency and accuracy. Its compatibility with SLC 500 systems facilitates seamless integration into existing industrial infrastructures.

    The module features a robust isolation mechanism, ensuring safety and reliability even under varying environmental conditions. Its open-type enclosure allows for easy access and maintenance, contributing to overall system uptime.

    Key benefits include reduced downtime, enhanced system reliability, and improved energy management, all of which contribute to cost savings and productivity gains. The Allen-Bradley 1746-OV16 is a testament to Allen-Bradley‘s commitment to delivering high-quality, cutting-edge solutions for industrial automation.

    Whether you’re looking to upgrade an existing system or build a new one from the ground up, the Allen-Bradley 1746-OV16 offers unparalleled performance and reliability. It’s a strategic investment that will undoubtedly elevate your automation capabilities.
