B&R 3D0486.6

B&R 3DM486.6 is a Digital Mixed Module (DM) that integrates 16 digital inputs (DI) and 16 digital outputs (DO). It is widely used for field signal acquisition and control.

Below are the detailed specifications and features of this module:

1. Core Functions

Digital mixed I/O: Provides 16 digital input channels (DI) and 16 digital output channels (DO), enabling connection to field devices such as sensors and actuators.
Expansion module: The module itself does not include a communication interface and is typically used together with a Power Panel or a CPU module to obtain communication capabilities.

2. Technical Specifications

Supply voltage: 24 V DC.
Input type: Dry contact inputs, supporting PNP / NP (non-PNP) wiring configurations.
Output type: Dry contact outputs, driven by solid-state relays (SSR), providing highly reliable switching control.
Input current: Typically around 5 mA.
Module position: The “3” in the model number usually indicates installation in slot 3 of the backplane, or possibly the third level of a control panel, depending on the system design.
