MOOG G772K240A Servo Valve Overview
MOOG G772K240A is a high-performance two-stage electro-hydraulic servo valve from the G770 series, designed for precise control of hydraulic flow, pressure, position, speed, and force in demanding industrial and aerospace systems.
1) Product Summary
The G772K240A converts an analog electrical signal into a proportional hydraulic flow output, enabling extremely accurate closed-loop motion control. It is widely used in aerospace testing, power plants, metallurgy, heavy machinery, and industrial automation.
Typical roles
- Flight simulators & aerospace test rigs
- Steel rolling mill hydraulics
- Injection molding machines
- Turbine & power plant control
- Automotive durability testing
2) Key Features
Servo valve architecture
- 2-stage design with torque-motor driven pilot stage
- Dual-nozzle flapper pilot and spool-type power stage
- Mechanical feedback via cantilever spring
- Fail-safe spring-centered spool (returns to neutral on signal loss)
Performance highlights
- High dynamic response and bandwidth
- High resolution & low hysteresis
- Excellent linearity and repeatability
- Rugged stainless-steel construction
- Field adjustable null bias
3) Technical Specifications (Typical)
| Parameter | Value |
|---|---|
| Type | Two-stage electro-hydraulic servo valve |
| Rated pressure | up to 210 bar / 3000 psi |
| Flow capacity | up to 240 L/min (variant dependent) |
| Command signal | ±10 V or 4–20 mA |
| Rated current | ~37 mA |
| Frequency response | ≥60–150 Hz (config dependent) |
| Hysteresis | <0.1–1% FS |
| Temperature range | −54°C to +120°C (approx.) |
| Medium | Hydraulic oil |
| Mounting | Baseplate |
4) Advantages in Real Applications
Precision control
- Accurate position, force and speed control for closed-loop systems
- Very fast response enables dynamic testing and motion simulation
Reliability & safety
- Fail-safe neutral position if signal lost
- Long service life and contamination-resistant design
Flexibility
- Can operate as 3-way or 4-way flow control valve
- Compatible with many hydraulic fluids and harsh environments
5) Maintenance & Installation Notes
- Hydraulic oil must be filtered to ≤10 μm cleanliness.
- System flushing required before installation.
- Sealed oil tank with air filtration recommended.
6) Lifecycle / Replacement Info
- Some distributors list G772K240A as discontinued or replaced by newer variants within the G77X family.
