National Instruments PXIe-4145 4-Channel High-Speed Digitizer

In stock

The National Instruments PXIe-4145 is a high-performance 4-channel digitizer designed for advanced signal acquisition and analysis in test and measurement applications. It supports up to 100 MS/s sampling rate and offers a wide bandwidth, making it ideal for use in aerospace, defense, automotive, and communications industries.

Tags: NI, NI PDF, NI Sensor, NI Sensor Motor, PXLE-4145, PXLE-4145 PDF

SKU: 17898416

Module Type:High-Speed Digitizer

Vendor:National Instruments

Model Number:PXIe-4145

Sampling Rate:Up to 100 MS/s

Resolution:14 bits

Input Channels:4 differential or 8 single-ended

Bandwidth:100 MHz

Analog Input Range:+/-10V

Trigger Modes:Software and hardware triggers supported

Connectivity:PXI Express

Compatibility:Works with NI software and compatible PXI modules

The National Instruments PXIe-4145 is a cutting-edge solution for high-performance data acquisition. It features a robust design with up to 4 analog input channels capable of sampling at rates up to 10 MS/s per channel. With a resolution of 16 bits and a wide analog input range of +/-10V, it ensures precision and reliability in your measurements. The module comes equipped with 32-bit digital I/O for versatile signal processing capabilities. Designed for integration into PXI Express systems, it offers a PCIe x4 Gen 2 interface for high-speed data transfer. The PXIe-4145 is supported by leading software platforms including NI LabVIEW, DIAdem, and MATLAB, making it easy to integrate into existing workflows. Its compact size and rugged construction make it ideal for use in demanding industrial settings.

NI PXle-4145
