Pacific Scientific SCE905AN-002-01 Servo Drive Module, Advanced Motion Control

Model Number:SCE905AN-002-01

Manufacturer:Pacific Scientific

Drive Type:Digital Servo Drive

Motor Compatibility:Brushless Three-Phase Permanent Magnet Motors

Control Technology:Digital Signal Processing (DSP)

Position Resolution:24-bit Resolver-to-Digital Conversion

Power Supply Compatibility:480 VAC (North America), 400 VAC 3-phase (Europe)

Communication Interface:Standard Industrial Control Protocols

Current Control:Advanced Signature Series Sinusoidal Current Control

Auto Tuning:Digital Auto-Tuning for Predictable Setup

Form Factor:Modular Design with User-Removable Option Cards

Mounting Type:Panel Mount / DIN Rail Mount (varies by model)

Protection Features:Overcurrent, Overvoltage, Overtemperature

Operating Temperature:-10°C to +65°C (standard)

Certifications:CE, UL, RoHS Compliant

    The Pacific Scientific SCE905AN-002-01 digital servo drive is engineered for high-precision industrial applications, delivering superior control performance through its advanced digital signal processing technology. Designed for seamless integration with programmable logic controllers and industrial automation systems, this drive ensures optimal motor control with minimal torque ripple and highly responsive dynamic performance.

    Featuring a modular architecture with user-removable interface tabs, the SCE905AN-002-01 offers flexibility in configuration and ease of maintenance. The drive supports both position and velocity control modes, making it suitable for a wide range of applications including CNC machining, robotics, semiconductor manufacturing, and automated test equipment. Its compatibility with both 480 VAC (North America) and 400 VAC (Europe) power systems allows for global deployment without additional power conversion hardware.

    The drive’s digital auto-tuning functionality simplifies setup and ensures consistent performance across varying load conditions. With 24-bit encoder feedback resolution, the system achieves micro-level precision, essential for high-accuracy applications. Additionally, the drive incorporates a robust protection system that guards against overcurrent, overvoltage, and overheating, prolonging the lifespan of both the drive and connected motor.

    Built with industrial reliability in mind, the SCE905AN-002-01 features durable construction materials and is designed to operate in harsh environments. It supports a wide temperature range and is engineered to withstand vibration and electrical interference commonly found in manufacturing and industrial settings. This ensures consistent operation and minimal downtime, even in the most demanding applications.

    For ease of use and integration, the drive comes with comprehensive technical documentation and software support. Engineers and technicians can leverage intuitive configuration tools to quickly set up and optimize performance parameters. Whether used in new installations or as a retrofit solution for existing systems, the Pacific Scientific SCE905AN-002-01 delivers reliable, high-performance motion control tailored to the needs of modern industrial applications.
