Tektronix 5B42 Arbitrary Function Generator, AFG Module

Output Channels:2

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Frequency Range:0.1 µHz to 20 MHz

Amplitude Range:±20 Vp-p into 50 Ω

Resolution:14-bit vertical resolution

Sampling Rate:250 MSa/s

Memory Depth:8 kpts

Phase Control:0 to 360 degrees

Bandwidth:20 MHz (-3 dB)

    The Tektronix 5B42 Arbitrary Function Generator provides a robust solution for generating precise waveforms for various test scenarios. With its advanced digital signal processing capabilities, this device ensures accurate and reliable performance across a broad frequency range. The user-friendly interface includes a 5-inch TFT color LCD display, allowing for easy parameter adjustments and real-time monitoring. Key features include programmable function keys, user-settable default values, and multi-language support, making it versatile for global use. The compact design of just 65 mm depth ensures it can fit seamlessly into any laboratory setup. The generator supports multiple communication interfaces, including USB, Ethernet, GPIB, and RS-232, facilitating integration with existing systems and networks. Whether for research and development or quality assurance, the Tektronix 5B42 is an essential tool for modern engineering laboratories.
