XYCOM XVME-530 PCB

XYCOM XVME-530 Overview

The XYCOM XVME-530 is an 8-channel isolated analog output module based on the VME-bus architecture, with its core component being the XVME-530 PCB (70530-001).

Item	Description
Module Type	8-channel isolated analog output (AOUT) module
Resolution	12-bit D/A converter
Output Channels	8 independent channels, each configurable via jumpers for voltage or current output
Voltage Output Ranges	0-5 V, 0-10 V, ±2.5 V, ±5 V, ±10 V
Current Output Range	4-20 mA
Optical Isolation	300 V isolation per channel to prevent interference between digital logic and analog signals
Gain/Offset Calibration	Individually adjustable for each channel, with a maximum total error of ±0.5 LSB
Power Supply	Onboard DC-DC converter, compliant with VME-bus power standards
Application Fields	Process control, proportional valve actuation, variable-speed motor drives, temperature control, set-point control, instrumentation, and other industrial automation scenarios
Part Numbers	70530-001 (PCB) / XVME-530 (Complete Module)

Key Features

• High Accuracy and Configurability:
  The 12-bit resolution combined with adjustable gain and offset enables precise output control with a total error within ±0.5 LSB, ideal for high-accuracy control loops.
• Flexible Voltage/Current Output Options:
  Output modes can be easily switched between multiple voltage ranges or 4-20 mA current through jumper settings, enhancing system design flexibility.
• 300 V Optical Isolation:
  Each channel provides 300 V optical isolation, ensuring electrical safety and noise immunity between analog outputs and the VME digital logic—well-suited for harsh industrial environments.
• Compatible with Xycom Standard I/O Architecture:
  Fully compatible with Xycom XVME chassis and existing VME-bus racks/backplanes for seamless system integration.

Typical Applications

• Process Control: Driving proportional or control valves for closed-loop regulation.
• Motor Speed Control: Providing variable voltage or current signals to inverters or DC motor drivers.
• Temperature/Pressure Set-point Control: Generating precise set-point signals in laboratory or production systems.
• Instrument Calibration: Serving as a high-accuracy analog signal source for calibrating measurement instruments.

Conclusion

The XYCOM XVME-530 PCB (70530-001) is a VME-bus analog output module designed for 8 isolated channels, featuring 12-bit resolution, configurable voltage/current outputs, 300 V optical isolation, and per-channel adjustable gain/offset. It is widely used in industrial automation applications that require precise and reliable analog signal output.
