XYCOM xvme200-290

XYCOM XVME-200/290 Series Overview

The XYCOM XVME-200/290 series are VMEbus-based digital I/O modules that provide 32 TTL bidirectional I/O channels. They support full VME interrupt handling and port handshaking functions.

Key Specifications

• Form Factor:
  • XVME-200: 3U (single-height) module
  • XVME-290: 6U (double-height) module
• I/O:
  32 TTL (0 V–5 V) input/output channels with programmable direction and interrupt levels
• Power Supply:
  +5 V; typical current consumption 1.3 A, maximum 1.5 A
• Operating Environment:
  • Operating temperature: 0 °C to 32 °C
  • Storage temperature: −40 °C to 85 °C
  • Relative humidity: 5 % to 95 % (non-condensing)
• Mechanical Dimensions:
  • Single-height: 150 mm × 116.7 mm
  • Double-height: 160 mm × 233.4 mm
• Interface:
  Standard VMEbus connectors.
  • XVME-200 uses a PI backplane.
  • XVME-290/1 and XVME-290/2 provide front/rear I/O via JK1 and JK2 connectors in the P2 area.

Functional Features

• I/O buffering and timer functions implemented using the 68230 Parallel Interface/Timer (PIT) chip.
• Jumper-selectable configuration for base address, address modifier, interrupt level, and handshaking line direction, allowing flexible integration into different systems.
• Supports VME interrupt vectors, selectable from four interrupt sources, suitable for a wide range of real-time control applications.

Typical Applications

• Digital I/O expansion for industrial automation control systems
• High-speed I/O communication between fieldbus or PLC systems and host computers
• Laboratory instruments or test platforms requiring reliable operation in a VME environment
