ABB 5SHY3545L0016 GVC736BE101 semiconductor components

ABB 5SHY3545L0016

Type: Silicon Controlled Rectifier (SCR) / IGCT module, part of ABB’s ACS800 series of high-performance power semiconductor components.

Main Specifications

• Rated Current: 16 A
• Rated Voltage: 230 V (some documentation lists 220 V)
• Fast switching speed, low power loss, and high efficiency
• Package dimensions: approximately 32 mm × 18 mm × 81 mm

Functions and Features

• Built-in overload and short-circuit protection; operates reliably under harsh industrial conditions
• Manufactured with advanced production processes for long service life and high reliability
• Suitable for AC/DC motor speed control, power regulation, and servo drive systems in high-power applications

Commonly Paired Components

• 3BHB020720R0002 – Digital Input / Control Module
• 3BHE019719R0101 – Power Module

---

ABB GVC736BE101

Type: IGCT (Integrated Gate-Commutated Thyristor) control module, part of ABB’s IGCT product line.

Main Specifications

• Dimensions: approximately 20 cm × 15 cm × 10 cm
• Weight: around 1.5 kg
• Compatible with 5SHY3545L0016 and related 3BHB / 3BHE modules

Functions and Features

• Multifunctional control supporting high-voltage and high-current operation for a wide range of industrial automation systems
• Offers fast switching, low losses, and high efficiency
• Compliant with IEC 60947-5-1, IEC 60947-5-5, and IEC 60664-1 international standards

---

Integrated Application

The 5SHY3545L0016 and GVC736BE101 modules are often used together within the same control system, forming a complete power conversion and control chain.
Typical applications include:

• Large-scale variable-frequency drives (VFDs)
• Power supplies for industrial robots
• Smart manufacturing production lines
• Power regulation and protection in high-voltage distribution systems.
