BEI H25E-F1-SS-10 High Precision Position Sensor Module

Brand:BEI

Model:H25E

Submodel:F1-SS-10

Type:Absolute Encoder

Resolution:25-bit

Operating Voltage:5V DC

Shaft Diameter:6mm

Shaft Length:30mm

Mounting Style:Hub Coupling

Interface:RS-485

Operating Temperature Range:-40°C to +85°C

Protection Rating:IP67

Weight:0.2kg

Dimensions:Diameter 60mm x Length 70mm

    The BEI H25E-F1-SS-10 is a high-precision incremental encoder designed for use in industrial automation systems where precise position feedback is critical. This encoder features a robust design with an IP67 protection rating, ensuring reliable operation in harsh environments. With a resolution of 4096 PPR, it provides accurate position data even in high-speed applications. The output type is incremental, making it compatible with a wide range of control systems. The encoder operates within a broad temperature range from -40°C to +85°C, ensuring stable performance under varying environmental conditions. The mechanical life of up to 50 million pulses guarantees long-term reliability and durability. The frequency response up to 25 kHz ensures smooth and continuous feedback, making it suitable for high-performance applications.
