GE DS3800HPBD1D1C Speedtronic Turbine Control Board

Board Type:General Electric DS3800HPBD1D1C

Compatibility:For use with GE Mark IV Speedtronic Turbine Control Systems

Mounting Method:Clips and screws

Power Port:Large, located on one edge

Diodes:Around twenty, varying in color and size

LEDs:Two red indicators

Toggle Switch:Small silver toggle

Jumper Ports:Several pairs with black covers

    The DS3800HPBD1D1C is a critical piece of equipment designed specifically for use within General Electric’s Mark IV Speedtronic Turbine series. Its robust design ensures seamless integration and operation within various industrial applications.

    This control board features a large power port along one edge, which makes it easy to connect to power sources. With approximately twenty diodes of varying sizes and colors, the DS3800HPBD1D1C offers a comprehensive visual interface for operators. Two red LEDs provide clear indications of operational status, while a small silver toggle switch allows for quick adjustments.

    The inclusion of multiple jumper ports, covered by black caps, provides flexibility in customizing the board’s functionality. This feature allows technicians to modify energy distribution according to specific project requirements without needing complex rewiring.

    Designed for durability and efficiency, the DS3800HPBD1D1C is built to withstand the rigorous demands of industrial settings, ensuring long-term reliability and performance. Its compatibility with the Mark IV Speedtronic system guarantees seamless integration with existing infrastructure, making it a reliable choice for any upgrade or replacement scenario.
