Schneider NWBP85002 – Modbus Plus 4-Port Bridge, for Automation Platforms

Communication Protocol:Modbus Plus

Number of Ports:4

Data Transfer Rate:Up to 1 Mbps

Operating Voltage:12V DC to 24V DC

Operating Temperature Range:-20°C to +55°C

Connection Type:RS485

Protocol Compatibility:Modbus, CANopen, DeviceNet, Profinet

Power Supply:Internal power supply

Dimensions:89mm x 89mm x 24mm

Weight:Approximately 100g

    The Schneider NWBP85002 Modbus Plus Bridge is an essential component for industrial automation systems, designed to facilitate communication between various devices on a network. This robust bridge supports Modbus Plus protocol, enabling efficient data exchange in complex industrial settings.

    With its four ports, this bridge allows for the connection of up to four devices simultaneously, optimizing the management of resources and enhancing system reliability. Its compatibility with other protocols such as CANopen, DeviceNet, and Profinet ensures seamless integration with a wide range of industrial equipment.

    Featuring a 1 Mbps data transfer rate, the NWBP85002 ensures fast and reliable data transmission, critical for real-time operations in manufacturing environments. It operates within a temperature range from -20°C to +55°C, making it suitable for use in a variety of industrial climates.

    Equipped with an internal power supply, the bridge requires a voltage range of 12V DC to 24V DC, providing flexibility in installation and maintenance. The compact size of 89mm x 89mm x 24mm and a lightweight design of approximately 100g make it easy to integrate into existing setups without compromising on functionality.

    Designed with durability and ease of use in mind, the Schneider NWBP85002 Modbus Plus Bridge is a valuable addition to any industrial control system, offering enhanced performance and connectivity for streamlined operation and monitoring.
