SMC CDU20-25D – High-Performance Double-Acting Cylinder

Working Pressure (Max):0.8 MPa

Bore Diameter (Standard):20 mm

Stroke Length (Options):50 mm, 75 mm, 100 mm

Travel Speed (Approx.):0.3 m/s

Operating Temperature Range:-10°C to +60°C

Load Capacity (Nominal):2 kg

Material:Aluminum alloy

Connection Type:Threaded rod

Operating Medium:Compressed air

Actuation Type:Single-acting

Safety Rating:Class 2, Category 2

    The SMC CDU20-25D boasts an innovative design that ensures smooth and precise movement in industrial automation systems. Its compact size and lightweight construction make it ideal for space-constrained applications without compromising on performance.

    Equipped with advanced sealing technology, this cylinder maintains high efficiency even under varying pressures and temperatures. The use of high-quality aluminum alloy contributes to its durability and resistance to wear and tear.

    With a stroke length of 25mm and a bore diameter of 20mm, the CDU20-25D provides ample force and displacement capabilities suitable for various industrial tasks. Its rod flange mounting style facilitates easy integration into existing machinery.

    Featuring a robust and corrosion-resistant design, the SMC CDU20-25D is engineered to withstand harsh operating conditions, ensuring long-lasting reliability in manufacturing, robotics, and material handling applications.

    For optimal performance, the cylinder is recommended to operate within a pressure range of 0.05 to 0.7 MPa, maximizing efficiency while minimizing energy consumption. The 1/4 NPT port size allows for seamless connection to a wide range of hydraulic systems.
