Spectrum Controls 1746SC-INI4VI Analog Input Module – High-Resolution Input Solution for Industrial Automation

Model Type:Industrial Automation

Manufacturer:Spectrum Controls

Model Number:1746SC-INI4VI

Number of Channels:4 Analog Inputs

Input Voltage Range:-10VDC to +10VDC

Input Current Range:±5 mA

Resolution:12-bit

Accuracy:+/- 0.25% of full scale

Environmental Conditions:Operating Temperature: -20°C to 50°C, Storage Temperature: -40°C to 70°C

Power Consumption:Less than 20mA @ 5VDC

Connectivity:RS-485, DeviceNet, CANopen

Dimensions:88mm x 50mm x 35mm

Weight:Approx. 100g

    The Spectrum Controls 1746SC-INI4VI Analog Input Module is specifically engineered for environments requiring high accuracy and reliability in data acquisition. Its 4-channel design supports a wide range of voltage and current inputs, ensuring compatibility with diverse industrial sensors and measurement devices.

    Featuring a common mode voltage range of -20 to 20V, this module ensures robust performance under various environmental conditions, making it suitable for use in harsh industrial settings.

    With a precision of 1 LSB for the input range of -10 to 10VDC, this module guarantees exceptionally accurate readings, critical for applications where minute variations can impact operational efficiency and safety.

    The open-type enclosure allows for easy integration into existing systems, while the backplane isolation provides a safeguard against electrical interference, ensuring stable operation.

    Operating within a temperature range from -40°C to +70°C, this module is built to withstand extreme conditions, offering a long service life in industrial automation setups.

    Equipped with efficient power consumption of just 5W, the Spectrum Controls 1746SC-INI4VI Analog Input Module optimizes energy usage without compromising on performance, contributing to cost-effective and sustainable industrial operations.
