ABB CDP312 Control Panel Keypad, Industrial Automation Solutions

Communication Protocol:Modbus

Communication Speed:9600 bit/s

Station Connectivity:Up to 31 drives and 1 panel

Unique ID Requirement:Each station must have a distinct ID

LED Indicators:Panel Link, Motor Speed, Motor Torque, Actuator Parameters, Function

Operational Commands:Locate, External Control, Reset, Reference Setting

Display:LCD text display

Keys:Keypad with forward start, reverse stop, reference setting functions

    Engineered for reliability and precision, the ABB CDP312 Control Panel Keypad ensures smooth operation in diverse industrial settings, enhancing productivity and reducing downtime.

    Connected via a Modbus protocol, it seamlessly integrates with ABB‘s drive systems, facilitating efficient communication and control over multiple drives from a single interface.

    With support for up to 31 drives, this keypad allows for scalable automation solutions, catering to both small-scale and large-scale production lines.

    Each station requires a unique ID number, ensuring a secure and organized connection within the network, which prevents interference and enhances system reliability.

    Featuring an LCD text display and 11 programmable function keys, users can customize operational commands, streamlining workflow and increasing efficiency.

    An internal backup battery ensures continuous operation during power outages, safeguarding against potential disruptions and maintaining system integrity.
