Allen Bradley 1746-NIO4I – 4-Channel Analog Input Module for Industrial Automation

Model Type:SLC500

Model Number:1746-NIO4I

Manufacturer:Allen Bradley

Channels:4

Analog Input Voltage Range:-20 to +20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max)

Current Range:-10 to +10 VDC

Output Voltage Range:-10 to +10 V

Resolution:1 LSB

Overvoltage Protection:7.5 VAC RMS

Power Supply Voltage:24 VDC +/- 10%

Current Consumption:Backplane: 55 mA

Isolation:Backplane: 500 VDC, Enclosure: Open Type

LED Indicators:Status LED

Connection Cable:24-14 AWG

Mounting Method:Chassis

    Engineered for seamless integration into Allen-Bradley’s SLC 500 series PLCs, the 1746-NIO4I provides unmatched performance in industrial automation.

    With its robust design, the module ensures reliable operation under challenging environmental conditions, making it ideal for manufacturing floors and process control environments.

    Supporting both voltage and current signals, this versatile module caters to a wide range of applications requiring precise analog signal handling.

    Featuring high-speed sampling capabilities, the 1746-NIO4I enables real-time monitoring and control, enhancing operational efficiency and productivity.

    Manufactured using top-grade materials for durability and longevity, this I/O module offers maintenance-free operation, reducing downtime and increasing system uptime.
