GE Fanuc IC3600SPSV1D Relay Interface Module

Product Overview

The GE Fanuc IC3600SPSV1D is a Mark VIe IONet switch designed for industrial control networking applications. It belongs to the GE Mark VIe and Mark VIeS control system family and provides Ethernet communication between control-system devices and I/O networks. In particular, the H3A version is configured with 16 copper Ethernet ports and no fiber ports, making it suitable for installations that use conventional copper network connections.

Furthermore, the module is designed for real-time control environments where stable communication, straightforward network integration, and reliable operation are essential. As a result, it can serve as an important networking component within compatible GE industrial control architectures.

Technical Parameters

Key Features

This module offers several features that support industrial Ethernet communication. First of all, it provides 16 copper Ethernet ports, allowing multiple compatible devices to share the same network infrastructure.

In addition, the switch supports 10/100Base-TX communication through standard RJ-45 interfaces. At the same time, automatic speed and duplex negotiation helps simplify network integration.

Other notable features include:

• 16 copper Ethernet ports for network connectivity
• 10/100Base-TX Ethernet communication
• Standard RJ-45 interfaces for copper cabling
• No fiber-optic ports in the H3A configuration
• Support for IEEE 802.3, 802.3u, and 802.3x standards
• Automatic speed and duplex negotiation
• HP-MDIX auto-sensing
• LED indicators for network and power status
• Two independent DC power inputs
• Fanless natural-convection cooling
• Industrial temperature capability

Moreover, the redundant power-input arrangement can help improve network availability when properly integrated into the overall control-system design.

Hardware Structure

This module combines Ethernet interfaces, switching electronics, power-input circuitry, and status indicators within a compact industrial enclosure. Consequently, the device can provide network connectivity without requiring a large amount of cabinet space.

The 16 RJ-45 interfaces are intended for copper Ethernet connections. Unlike versions that include optical communication interfaces, the H3A configuration does not provide fiber ports. Therefore, it is particularly suitable for Mark VIe installations where the network infrastructure is based on copper Ethernet cabling.

In addition, its convection-cooled design eliminates the need for an internal cooling fan. This can simplify routine maintenance and reduce another potential mechanical failure point.

Industrial Applications

This module is primarily associated with GE Mark VIe control architectures. For example, it can be found in industrial environments where reliable communication between control-system components is required.

Typical applications include:

• Gas turbine control systems
• Steam turbine control systems
• Power generation facilities
• Industrial automation systems
• Process control networks
• GE Mark VIe IONet architectures
• Compatible Mark VIeS control environments

As a result, this module can be used as part of the communication infrastructure connecting controllers, I/O-related equipment, and other compatible network devices.

Product Value

For compatible Mark VIe installations that use copper Ethernet infrastructure, the  provides a practical industrial networking solution. Moreover, its 16-port configuration, redundant DC power inputs, compact construction, and fanless cooling make it suitable for demanding control environments.

Overall, this module is a useful choice for maintaining established GE Mark VIe network architectures. With proper installation, inspection, and system verification, it can support reliable Ethernet communication within industrial automation applications.
