Schneider AS-BADU-214 is an analog input module in the Schneider Electric Modicon series, typically used in PLC (Programmable Logic Controller) systems.

Below is a summary of the module’s main technical specifications and features:

1. Core Specifications

• Type: Analog Input Module
• Number of Channels: 8 input channels
• Input Voltage Range: 10 V to 30 V (commonly specified as 10–30 V DC), supporting 0–10 V input
• Compatibility: Designed for Schneider Modicon PLC systems, commonly used in TSX, M340, and related series

2. Main Functions

• Signal Acquisition: Converts on-site analog voltage signals (such as 0–10 V outputs from sensors) into digital signals for PLC program reading and processing.
• Accuracy and Response: Provides high sampling accuracy and fast response, making it suitable for applications requiring continuous analog monitoring, such as process control, temperature measurement, and flow monitoring.

3. Typical Applications

• Industrial Automation: Commonly used to connect various analog sensors, such as pressure sensors, temperature sensors (RTD/thermocouple), and potentiometers.
• Process Control: Widely applied in industries such as chemical processing and manufacturing for real-time monitoring of process parameters.

Summary

The AS-BADU-214 is a standard 8-channel, 10–30 V analog input module widely used in Schneider Modicon PLC systems, primarily for acquiring voltage signals from field sensors.
