ABB TVOC-2-240

1. Overview

The ABB TVOC-2-240 is a dedicated industrial gas sensing transmitter for continuous total volatile organic compound (TVOC) concentration detection. Different from civilian air sensors, it adopts high-sensitivity industrial gas sensing chip with anti-dust, anti-oil fume filtering structure, which effectively resists workshop oil mist, particulate dust and high humidity interference to avoid measurement drift and false alarms.
The sensor converts real-time TVOC concentration values into standard 4–20mA analog signals, which can be transmitted to DCS, PLC and local alarm controllers. It supports linkage control of workshop exhaust fans and fresh air ventilation equipment, automatically triggering alarms when VOC concentration exceeds safety thresholds to prevent flammable and toxic gas safety accidents. With wide working temperature range and IP54 protective shell, it runs stably year-round in printing, paint spraying, fine chemical and pharmaceutical production workshops to meet factory environmental protection emission supervision and occupational safety monitoring requirements.

 2. Technical Specifications

3. Key Features

Industrial High Anti-Interference Sensing Design: Built-in multi-stage filter to eliminate oil mist, dust and high humidity causing data drift and false alarms.
Real-Time Continuous TVOC Concentration Tracking: Captures trace volatile organic gas changes to ensure timely safety warning.
Universal 4-20mA Signal Output: Perfectly compatible with all mainstream industrial automation control systems for automatic ventilation linkage.
Wide Environmental Adaptability: Works reliably in low-temperature winter workshops and high-temperature coating production workshops.
Wall-Mounted Compact Structure: Simple on-site installation and wiring, low routine maintenance workload.
Factory Safety & Environmental Compliance Support: Provides accurate gas data for occupational safety supervision and factory emission environmental assessment.

 4. Structure and Composition

The TVOC-2-240 air quality sensor adopts an integrated wall-mounted structure, composed of high-sensitivity VOC sensing chip, multi-stage dust/oil filter assembly, signal amplification conditioning circuit and IP54 plastic protective housing.
External air enters the sensing cavity after multi-layer filtering to remove particulate pollutants, guaranteeing long-term stable sensing performance. The internal circuit has power anti-surge protection to avoid sensor burnout caused by workshop power fluctuation. Standard terminal wiring design simplifies field construction and maintenance replacement operations.

5. Application Fields

• Coating & Spraying Workshops: VOC concentration monitoring for automobile, furniture paint spraying production lines
•  Printing & Ink Manufacturing Plants: Air quality detection in gravure, offset printing workshops with volatile ink
• Fine Chemical & Pharmaceutical Factories: Workshop toxic volatile gas safety monitoring for synthesis workshops
•  Industrial Environmental Protection Supervision: Factory exhaust gas pre-monitoring to meet emission standard requirements
• Intelligent Factory Ventilation Control: Link with exhaust fans to realize automatic air exchange control based on real-time TVOC data

—————————————————————
