UNIOP eTop05EB-11E50

1. Overview

UNIOP eTop05EB-11E50 This product is a compact 4.3-inch wide-screen color touch panel, positioned as a high-cost-performance and uncompromising low-cost solution while retaining the advanced functions and excellent performance of the eTOP500 series. Supporting the JMobile runtime environment, it serves as an ideal display and control terminal for small-scale industrial automation applications.

2. Main Specifications

Item	Specification
Display Screen	4.3-inch TFT color LCD with LED backlight and full-color display
Resolution	4.3-inch wide screen (Official pixel values not explicitly released; the conventional resolution for screens of the same size is 480×272)
Processor	ARM Cortex-A8 with a main frequency of 600 MHz
Ethernet Interface	Dual 100Mb Ethernet ports with built-in switch function
Other Interfaces	USB, serial ports (RS-232/RS-485, etc.), MPI (Multi-Point Interface)
Integrated Expansion Slot	Optional pluggable fieldbus/network module
Storage Expansion	SD card support
Software Platform	Supports JMobile Studio development environment; optional integrated IEC 61131-3 soft PLC (CODESYS V2/V3)
Warranty	5-year warranty

3. Product Features

High-Performance Core: Equipped with an ARM Cortex-A8 600 MHz processor, it delivers smooth human-machine interaction responses.

Dual Ethernet Port Design: Built with two 100Mb Ethernet ports and an integrated switch, it simplifies network wiring and adapts to interconnection of small-scale equipment.

Full-Metal Housing: Adopting innovative mechanical design and an all-metal body, it enhances durability and anti-interference capability.

Comprehensive Protection: All electronic boards are coated with protective materials to adapt to harsh industrial field environments.

Versatile Communication Capabilities: Integrated with Ethernet, USB, serial ports and MPI interfaces, and compatible with optional fieldbus expansion modules. The gateway function supports remote deployment and technical assistance.

Integratable Soft PLC: Optional built-in CODESYS soft PLC compliant with the IEC 61131-3 standard realizes integrated HMI and control functions.

Multi-Color Front Panel Options: Standard black front panel model (U3P1), with optional white (U1P1) and silver (U2P1) versions available.

4. Structure and Composition

The hardware structure of the eTOP504 includes the following components:

Power Supply Interface
Serial Port
Dual Ethernet Ports
USB Port
Expansion Slot for Plugin Modules
SD Card Slot

Featuring a compact overall structure and an all-metal enclosure, the product is fitted with a black plastic/metal border on the front panel.

5. Application Fields

The eTOP504 is widely applied in the following industrial automation scenarios:

Human-machine interface for small mechanical equipment
Data monitoring and collection on industrial sites
Remote equipment diagnosis and maintenance
Display terminal for embedded control systems
Applicable to shipping, automotive, oil and gas, construction and other industries with relevant industry certifications

6. Installation and Maintenance

Installation Method: Adopts embedded cutout installation, compatible with dedicated mounting boxes (such as inclined mounting boxes applicable to 1.2mm thick iron sheets).

Front Panel Protection: The front panel features an IP65 protection grade (dustproof and waterproof), suitable for harsh industrial environments.

Maintenance Guidelines:

Clean the front panel regularly with a soft dry cloth to wipe the touch screen;
Check the tightness of power connections and communication cables periodically;
Use an SD card for application program backup and firmware upgrades;
PROTOFOIL series protective foils can be applied to the screen surface for scratch resistance and UV protection;
For specific installation cutout dimensions and electrical wiring specifications, please refer to the official eTOP504 Tech-Note and JMobile Studio operation manual.

————————————————————–
