UNIOP ETOP310U201

Product Overview

This UNIOP ETOP310U201 industrial HMI belongs to the UniOP eTOP Series 500. It features a black front panel, widescreen TFT color touchscreen, dual Ethernet and USB ports, and built-in JMobile runtime.

Designed for industrial machine and process control, this HMI serves as a on-site visual operation platform. It supports real-time production data monitoring, parameter adjustment, alarm viewing, and interactive control with PLCs and other automation devices for daily industrial operation needs.

Main Specifications

Parameter	Specifications
Brand	UniOP / Exor
Product Series	eTOP Series 500
Display Size	13.3 inches
Display Type	Widescreen TFT color touchscreen
Resolution	1280 × 800 pixels
Touch Technology	Resistive touchscreen
Backlight	LED
Ethernet	2 × Ethernet ports
USB	2 × USB ports
Power Supply	24 VDC
Operating Temperature	0 to +50 °C
Front Protection Grade	IP66
Rear Protection Grade	IP20
Approx. Weight	2.8 kg
Front Panel Dimensions	336 × 267 mm
Cutout Dimensions	326 × 256 mm
Depth	Approx. 60 mm including terminal area

As the black-panel model of series, this industrial HMI comes with standard Ethernet, USB interfaces and JMobile runtime. With IP66 front protection and a 0°C to +50°C operating range, it fits most standard industrial environments.

Display and Operator Interface

This 13.3-inch widescreen industrial display offers ample viewing space. Its 1280 × 800 resolution clearly shows process graphics, real-time data, alarms, trend curves and operation buttons, enabling precise on-site information acquisition.

The industrial resistive touchscreen delivers stable and responsive operation for harsh on-site conditions. Supported by the JMobile environment, the platform provides vector graphics, multi-language support, alarm processing, recipe management, user permission control and data visualization to cover full industrial operation scenarios.

The U3P1 black front panel offers a clean, professional look for control cabinets and operator stations. series also includes U1P1 (white) and U2P1 (silver/grey) variants for diverse equipment style matching.

Connectivity and Software Functions

This full-featured industrial HMI is not merely a display device. Its rich interfaces and software functions enable stable data exchange and control between operators and industrial controllers.

It integrates comprehensive hardware and software resources as below:

Dual Ethernet ports for stable network communication and data transmission
Dual USB interfaces for peripheral connection and equipment daily maintenance
Built-in serial communication capability, compatible with multiple traditional industrial communication protocols
SD card storage support for local data recording and program backup
Plug-in module expansion interface, supporting subsequent function upgrade and expansion
Pre-installed JMobile runtime environment, supporting independent operation of customized industrial programs
Massive built-in PLC and factory system communication drivers, with strong compatibility
Remote monitoring and remote control functions, realizing off-site equipment management

Thanks to abundant built-in communication drivers, this HMI seamlessly connects with mainstream PLCs and factory automation systems, adapting to various automation architectures and realizing unified on-site equipment monitoring.

Applications and Installation

Featuring strong environmental adaptability and flexible control functions, this industrial HMI is widely used in industrial scenarios requiring graphical monitoring and operation, including:

Factory integrated automation control
Industrial machine single-unit control
Automated production line operation monitoring
Packaging machinery automated control
Industrial process real-time monitoring
Material handling and logistics equipment control
Building and facility intelligent automation
Industrial equipment data visualization
PLC-based automated control systems
OEM customized mechanical equipment matching

This HMI supports cabinet embedding and panel mounting. Its IP66 front panel resists industrial dust and water splash for harsh working conditions. The IP20 rear side requires protective cabinet installation for safety.

Install strictly per official dimensions. Reserve sufficient wiring and heat dissipation space for rear connectors to ensure stable equipment operation and easy maintenance.

Maintenance and Replacement Guidelines

Daily maintenance focuses on touchscreen cleaning and connection inspection. Regularly clean the screen, check power and communication ports, fasten mounting parts and ensure cabinet ventilation to prevent equipment faults.

Verify panel style before replacement to avoid mismatch. series has three panel color variants: white, silver/grey and black for different application scenarios.

The black-panel HMI fully matches original legacy equipment in display size, interfaces, mounting dimensions and JMobile environment. It is a highly compatible, cost-effective replacement solution to sustain stable operation of old UniOP automation systems.

————————————————————–
