Foxboro RH914TN 16 Channel Analog Input Card

Foxboro RH914TN 16 Channel Analog Input Card is a 16-channel analog input module in the Foxboro I/A Series (Compact 200 Series I/O), accepting 0–20.4 mA DC signals from field instruments such as 4–20 mA two-wire transmitters and self-powered 20 mA sources. Each channel is group-isolated and independent, with a 33 mA current limit, and the module communicates with its associated Field Control Module (FCM) or Field Control Processor (FCP) over a redundant 2 Mbps module Fieldbus. It is widely used for collecting process signals such as temperature, pressure, and flow in industrial automation systems.

Product Datasheet

• Brand: Foxboro
• Model: FBM211 (RH914TN)
• Series: I/A Series / Foxboro Evo (Compact 200 Series I/O)
• Product Name: Analog Input Module (0–20 mA Input Interface Module)
• Channels: 16, group-isolated and independent
• Input Range: 0–20.4 mA DC per channel (current limited to 33 mA)
• Input Signals: 4–20 mA two-wire transmitters or self-powered 20 mA sources
• Isolation: Galvanically isolated from ground and module logic
• Fieldbus: Redundant 2 Mbps module Fieldbus to FCM/FCP
• Module Part No.: P0914TN

Fault Troubleshooting and Common Questions

1. The module is not recognized by the DCS. Check the module’s seating, fieldbus connection, and system power. Verify the FBM211 is correctly configured in the I/A Series control configuration and that the installed revision is supported.
2. Input signals are not detected correctly. Check the field wiring, terminal connections, and the connected instrument. Verify that the transmitter supply and loop wiring are correct and that the input channel is configured properly.
3. Readings are inaccurate or unstable. Inspect field wiring, grounding, and shielding. Verify the input range and engineering units match the configured channel, and confirm the connected signal is within the 0–20.4 mA range.
4. Can the FBM211 RH914TN replace another Foxboro analog input module? Not without verification. Compare the full part number, channel configuration, input range, termination assembly, hardware revision, and compatibility with the specific I/A Series system before replacement.

Safety Precautions

• Isolate power and follow lockout/tagout procedures before removing or installing the module.
• Use electrostatic discharge protection when handling electronic assemblies.
• Verify terminal assignments and field wiring before energizing the module.
• Do not connect field signals until the electrical ratings have been confirmed.
• Use qualified personnel for troubleshooting and commissioning in operating process systems.

Frequently Asked Questions

Q1: What is the Foxboro FBM211 RH914TN? It is a 16-channel analog input module in the Foxboro I/A Series, accepting 0–20.4 mA DC signals from two-wire transmitters and self-powered 20 mA sources.

Q2: How many input channels does the module have? The FBM211 has 16 group-isolated, independent input channels with a per-channel range of 0–20.4 mA DC.

Q3: Which system is the module used in? It is used in the Foxboro I/A Series (Compact 200 Series I/O) and communicates with FCM or FCP over a redundant 2 Mbps module Fieldbus.

Q4: What should be checked before purchase? Verify the model label, full part number, hardware revision, termination assembly, condition, and compatibility with the specific I/A Series system.
