SCHNEIDER S74D-PB0-F0V0 is an industrial control relay manufactured by Schneider Electric. The main technical specifications and dimensional information of this product are as follows:
1. Core Technical Specifications
The key technical parameters of this relay include:
- Mechanical life: 30 Mcycles (30 million operations)
- Maximum operating frequency: 180 cycles/min
- Response time: 28 ms
- Power consumption:
- Inrush power: 5.4 W
- Hold-in power consumption: 5.4 W
- Pick-up voltage: Minimum pick-up voltage of 17 V
- Pick-up current: Minimum pick-up current of 5 mA
- Non-overlap time:
- 1.5 ms between the NC (normally closed) and NO (normally open) contacts during energization
- 1.5 ms during de-energization
- Insulation resistance: > 10 MΩ
2. Mechanical Structure and Dimensions
The overall dimensions of the relay are:
- Height: 77 mm (3.03 in)
- Width: 45 mm (1.8 in)
- Depth: 93 mm (3.7 in)
- Weight: Approximately 0.58 kg (1.28 lb)
3. Environmental Performance and Durability
- Shock resistance:
- 15 Gn when the relay is de-energized
- 10 Gn when energized
- Shock duration: 11 ms
- Complies with IEC 60068-2-27
- Vibration resistance:
- 4 Gn when the relay is de-energized
- 2 Gn when energized
- Frequency range: up to 300 Hz
- Complies with IEC 60068-2-6
4. Summary
The SCHNEIDER S74D-PB0-F0V0 is a relay designed for industrial environments, featuring a high mechanical life of 30 million operations and a fast response time of 28 ms. It is suitable for control systems requiring frequent switching. The relay supports a low pick-up voltage of 17 V, has low power consumption (only 5.4 W), and offers excellent resistance to mechanical shock and vibration.
