Siemens 6SE3215-8DB40 MICROMASTER Vector Drive

In stock

Siemens 6SE3215-8DB40 MICROMASTER Vector Drive is the MMV220/3 frequency inverter — 2.2 kW constant torque, three-phase 380–500 V AC ±10% (unfiltered), with V/f and sensorless vector control, Fast Current Limit, built-in PID and RS-485 USS communication, overload 150%/60 s and 200%/3 s per the original Siemens order text. Compact IP20 wall-mount (184×149×172 mm), 0–50 °C; Made in Germany.

Tags: ABB 216BM61B HESG448267R1021, ABB DPW03, ABB DPW03 Power Supply, DPW 03, DPW 03 Actuator, DPW03, DPW03 Industrial

SKU: 7559732-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-2-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1-1

The Siemens 6SE3215-8DB40 MICROMASTER Vector Drive is the MICROMASTER Vector MMV220/3 frequency inverter — a 2.2 kW, three-phase 380–500 V AC unfiltered drive from the Siemens MICROMASTER Vector family, providing V/f and sensorless vector control with fast current limit for trip-free operation in industrial motor-drive applications.

Key Features

MICROMASTER Vector (MMV) frequency inverter — MMV220/3 type, unfiltered version
2.2 kW constant-torque rating
Three-phase input 380–500 V AC ±10%, 50/60 Hz
Overload capability: 150% for 60 s; 200% for 3 s
V/f control with sensorless vector control; Fast Current Limit (FCL)
Built-in PID for closed-loop process control; 15 V / 50 mA sensor supply
RS-485 (USS protocol) — up to 31 converters on one bus
Operating temperature 0–50 °C
Compact IP20 enclosure, wall mounting

Technical Specifications

Order Number: 6SE3215-8DB40
Type Designation: MICROMASTER Vector MMV220/3 (unfiltered)
Product Type: Frequency inverter / AC drive
Input Voltage: 3 AC 380–500 V ±10%, 50/60 Hz
Constant Torque Rating: 2.2 kW
Overload: 150% for 60 s; 200% for 3 s
Variable Torque: N/A
Control: V/f + sensorless vector control, FCL
Communication: RS-485 USS (up to 31 nodes)
Dimensions: 184 × 149 × 172 mm (H×W×D)
Enclosure: IP20, wall mounting
Ambient Temperature: 0–50 °C
Origin: Germany (Siemens)

Installation Notes

Verify the drive type (MMV220/3, 2.2 kW) and supply voltage against the nameplate before installation.
Mount the drive on a vertical wall/panel with adequate cooling clearance; observe ambient limit 0–50 °C.
Size input fuses and check motor cable lengths per the MICROMASTER Vector operating instructions.
Wire motor (U/V/W), control terminals (digital/analog inputs, relay outputs, RS-485) per the manual; use shielded control cable.
After power-up, set motor parameters and control mode via the parameter set; perform a jog test before normal operation.

Common Questions

What is the 6SE3215-8DB40? It is the Siemens MICROMASTER Vector MMV220/3 frequency inverter — 2.2 kW constant torque, three-phase 380–500 V AC, unfiltered version.

What is its overload capability? 150% for 60 s and 200% for 3 s.

What control modes does it support? V/f control and sensorless vector control, with Fast Current Limit and built-in PID (per the MICROMASTER Vector manual).
